Improved booms,sticks,buckets,prolong the service life of the machine.
Product Description
-
Improved booms,sticks,buckets,prolong the service life of the machine.
-
Smalland flexible,convenient for small terrain and narrow space operations
-
Structura parts are made of stainless steel or plastic to prolong service life
-
360-degree rotation,easy to leam,flexible operation,easy to master.
-
Hurmanized front gear mechanism ensures safe driving environment.
U-Power/Boliton/Kubota Engines/B-Link Manual Multi-Way Valve/Branded Travel Motor/Nine-Tooth Spline Gear Pump/Imported Hydraulic Cylinders and Hydraulic Pipes with Built-in NOK Seals/Adjustable Bulldozer Blade/Wear-Resistant Engineering Rubber Tracks/Adjustable Driver's Seat/Standard Bucket
Product Data
| Specification | Metric Value | Specification | Imperial Value |
| MODEL | R319 | MODEL | R319 |
| WEIGHT | WEIGHT | ||
| Operating Weight | 1000kg | Operating Weight | 2205lb |
| SIZE | SIZE | ||
| Total Transport Length | 2256mm | Total Length | 89in |
| Total Transport Width | 917mm | Total Width | 36in |
| Total Transport Height | 2215mm | Total Height | 87in |
| Maximum Digging Radius | 2823mm | Max. Digging Radius | 111in |
| Maximum Digging Depth | 1563mm | Max. Digging Depth | 62in |
| Maximum Digging Height | 2478mm | Max. Digging Height | 98in |
| Maximum Dumping Height | 1826mm | Max. Dumping Height | 72in |
| Counterweight Ground Clearance | 379mm | Counterweight Ground Clearance | 15in |
| DRIVE | DRIVE | ||
| Engine Brand | Youpu / Bison / Kubota | Engine Brand | Youpu / Bison / Kubota |
| Engine Model | 192F / XR2100 / D722 | Engine Model | 192F / XR2100D722 |
| Output Power | 7.5 / 10 / 10.2kW | Output Power | 10.2 / 13.6 / 13.9ps |
| WALKING CHARACTERISTICS | WALKING CHARACTERISTICS | ||
| Travel Speed | 0-1.5km/h | Walking Speed | 0-0.93mph |
| Climbing Angle | 30° | Climbing Angle | 30° |
